    Mini Electric Tourist Bus With Four Wheels Hydraulic Braking System

    Ask Lasest Price
    Brand Name : Topcart
    Model Number : TG-14
    Certification : CE
    Price : 3000-4500 USD PER UNIT
    Payment Terms : Western Union, L/C, T/T
    Supply Ability : 500 UNITS PER MONTH
    Delivery Time : 10-15 WORK DAYS
    • Product Details
    • Company Profile

    Mini Electric Tourist Bus With Four Wheels Hydraulic Braking System

    Yellow 14 Seater electric sightseeing bus tour bus new electric car 72V china electric bus


    1. Standard color: White;arractive design and powerful in appearance , with strong carrying capacity and lower noise.

    2. Standard feature: Front and Rear lights; Rear View mirrors; Electric Horn; Rustproof body structure

    3. Small turning radius; and smart steering system ;Whole style steel rear axle;

    4. Can be easy modified to transportation vechicles,

    5. CE certificate for whole carts;

    6. Import main parts:Curtis controller(From USA).

    7. Four wheels hydraulic braking system and independent parking brake


    Performance


    ItemDescription
    systemDC systemAC system
    Passenger Capacity1414
    Climbing capacity(full load)20%25%
    Max. forward speed23km/h45km/h
    Endurance mileage50-70km60-80km
    Charging time8-10 hours8-10 hours
    Max.loading weight510kgs510kgs
    Min.turning radius5.1m5.1m
    Max. movement after brake at speed of 20km/h≤4m≤4m

    Dimensions


    ItemDescription
    Overall dimensions (L x W x H)5300x1500x2000mm
    Ground clearance150mm
    Wheelbase2850mm
    Front wheel tread (mm)1210mm
    Rear wheel tread (mm)1200mm

    Option Accessories


    To increase the sales value of our golf cart, we also provide many optional accessories.

    ItemOption descriptionItemOption description
    1E-key112-point seatbelt
    2Hinged windshield12Battery water refill system
    3Laminated windshield with wiper13Digital meter
    4Steel brush guard14EM brake
    5Front steel basket15Four wheel disc brake
    6Inner rear view mirror16Carlisle 205/50-10tyre with10inch wheel
    7Side rear view mirror17Ice box
    8Enclosure18Sand bottle
    9Sunshine cover19Sand rake
    10Golf bag cover20Ball washer

    Packing & Shipping


    Excar golf cart will be packed in steel crate


    ModelDimension(mm)20” container40” container
    A1H2/CCWith roof & windshieldWithout roof & windshieldWith roof & windshieldWithout roof & windshieldWith roof & windshieldWithout roof & windshield
    3400*1200*19003400*1200*12002 units4units6units12units
